Dimension: 217*83*46mm

Display: 3.5 inch TFT color screen 320*240

Case: Engineering plastics, anti-static coating, isolate high-frequency interference

CPU: 32-bit high speed CPU, ARM kernel, main frequency 98MHz

Battery: 4000 mAh

Developing environment: second development of C, C++, IDE Linux 2.6.3

Storage: Flash Memory 64Mbyte (can expand to 256Mbyte)

Internal memory: DRAM 32Mbyte (can expand to 64Mbyte)

External memory: 2G Micro SD card

Support type of card: Mifare Classic/Ultalight/DESFire, ISO14443A

Expanded sockets: one for SIM card, one for PSAM card, one for Micro SD card

Way of communication: GPRS

Working voltage: 3.7V

Data volume: 20M storage space

Printer: Thermal printer

Ticket dimension: 58*30mm

Update system and download parameter: Via 2G Micro SD card

Working temperature: -30°C -85°C

Storage temperature: -40°C -85°C

Power consumption: Smart power supply management method, 12V power supply

Standby electric current: <15mA
